$180

100-18 Milk cream separator 100L/H full metal
$180







SpecificationValue
Max. milk output, l/h 100
Milk bowl capacity, l 12
Max. butter-fat content in skimmed milk, % 0.05
Number of disks in drum, pcs 10-12
Drum rotational speed, rpm 10500 ±1000
Cream/skimmed milk volume proportion adjustment range 1:4 to 1:10
Power consumption, W, not more than 90
Supply voltage frequency, Hz 50
Supply voltage, V 220±10%
Height, mm 520
Bowl diameter, mm 365
Weight, kg(gross weight ) 6.2
Motor case
food grade aluminium
Cream and skim milk receiver food grade aluminium
Drum disks stainless steel
Float chamber food grade aluminium
Milk receiver(tank) food grade aluminium

This separator designed to separate whole milk into cream and skim milk with simultaneous decontamination. This separator for milk at the same time eliminates pollution, which appeared in the product after straining. Milk should be warmed to 40-50 degrees to get better results. Pour milk during rotation of bowl. In the meantime separator isolates the cream, and milk goes out through 2 tubes: on the one hand cream and on the other hand skim milk. Cream stream is less and has off-white color. A bluish skim milk flows by thick stream. Operating on the principle of rapid rotation of the drum, separator affects the milk by centrifugal force, so that separation of milk occurs. Drum of home separators runs at high speeds over 10000 rpm. Because of its high-speed milk is quickly divided into fat and fat-free parts.


Technical Features

• Max. milk output, l/h 100

• Drum rotational speed, rpm 10500 ±1000

• Number of disks in drum, pcs 10 to12

• Milk bowl capacity, l 12

• Max. butter-fat content in skimmed milk, % 0.05

• Cream/skimmed milk volume proportion adjustment range 1:4 to 1:10

• Power consumption, W, not more than 90

• Supply voltage, V 220±10% (It's need converter, if your native voltage is 110V)

    The map of voltage and frequency of the current in the different countriesof the world

Piccy.info - Free Image Hosting



• Supply voltage frequency, Hz 50

Overall dimensions, mm: - bowl diameter 365 - height 520 Weight, kg 5,5

Body: food grade aluminium

Cream and skim milk receiver: food grade aluminium

Drum disks: Stainless Steel

Float chamber: food gradealuminium

Milk receiver: food grade aluminium

 Detailed Instruction in English
